OPT & examination lights
OPT light
GSDMLED 2MC
Technical data:
- Central light intensity at a distance of 1 meter: 115.000 Lux
- Light field diameter d10: 170 mm
- Light field diameter d50: 100 mm
- Light intensity with one shadower: 36 %
- Light intensity with two shadowers: 48 %
- Light intensity on the ground of a normed tube: 100 %
- Light intensity on the ground of a normed tube with one shadower: 36 %
- Light intensity on the ground of a normed tube with two shadowers: 48 %
- Illumination depth 60 %: 580 mm
- Illumination depth 20 %: 1230 mm
- Colour rendering index Ra: 96
- Colour rendering index R9: 96
- Max. radiation in field in a distance of 1 meter: 356 W/m²
- Max. radiation in field in a distance of 0,80 meters: 529 W/m²
- Focusable light field size: 17-28 cm
- Colour temperature (Kelvin): 3750, 4000, 4250, 4500, 4750 K
- Temperature increase in head area: 0,5 °C
- Number of LED’s: 84
- Life span of LED’s: > 40.000 h
- Light head diameter: 49 cm
- Working distance: 60-150 cm
- Height adjustment: 118 cm
- Power consumption: 70 W
- Operating voltage: DC 24 V – 30 V
- Current: 2,9 A
Mounting options:
- Ceiling suspended
- Mobile on four castors
